INTRODUCTION
1
Imager Duo Operator’s Manual 1.9
Figure 1-5 Rear View, Imaging Station
Figure 1-6 Internal Components (Covers Removed)
Fuses (inside)
On/Off Switch
Power Cord
Firewire USB Serial
Interconnection Cables
to Image Processor Controller
Air Filter
Model/Rating Labels
Serial Number
Slide Cassettes in Slots 1 and 2
(Robot Shield Removed)
Slide Transfer Arm (Robot)
