HT66F0175/HT66F0185
A/D Flash MCU with EEPROM
HT66F0175/HT66F0185
A/D Flash MCU with EEPROM
Bit1 COM1EN:SCOM1/SSEG1orotherpinfunctionselect
0:Otherpin-sharedfunctions
1:SCOM1/SSEG1function
Bit0 COM0EN:SCOM0/SSEG0orotherpinfunctionselect
0:Otherpin-sharedfunctions
1:SCOM0/SSEG0function
SLCDC1 Register
Bit 7 6 5 4 3 2 1 0
Name COM5EN COM4EN COMSEGS5 COMSEGS4 COMSEGS3 COMSEGS2 COMSEGS1 COMSEGS0
R/W R/W R/W R/W R/W R/W R/W R/W R/W
POR 0 0 0 0 0 0 0 0
Bit7 COM5EN:SCOM5/SSEG5orotherpinfunctionselect
0:Otherpin-sharedfunctions
1:SCOM5/SSEG5function
Bit6 COM4EN:SCOM4/SSEG4orotherpinfunctionselect
0:Otherpin-sharedfunctions
1:SCOM4/SSEG4function
Bit5 COMSEGS5:SCOM5orSSEG5pinfunctionselect
0:SCOM5
1:SSEG5
Bit4 COMSEGS4:SCOM4orSSEG4pinfunctionselect
0:SCOM4
1:SSEG4
Bit3 COMSEGS3:SCOM3orSSEG3pinfunctionselect
0:SCOM3
1:SSEG3
Bit2 COMSEGS2:SCOM2orSSEG2pinfunctionselect
0:SCOM2
1:SSEG2
Bit1 COMSEGS1:SCOM1orSSEG1pinfunctionselect
0:SCOM1
1:SSEG1
Bit0 COMSEGS0:SCOM0orSSEG0pinfunctionselect
0:SCOM0
1:SSEG0
