SLCDC2 Register
Bit 7 6 5 4 3 2 1 0
Name SEG13EN SEG12EN SEG11EN SEG10EN SEG9EN SEG8EN SEG7EN SEG6EN
R/W R/W R/W R/W R/W R/W R/W R/W R/W
POR 0 0 0 0 0 0 0 0
Bit7 SEG13EN:SSEG13pinfunctionselect
0:Otherpin-sharedfunctions
1:SSEG13function
Bit6 SEG12EN:SSEG12pinfunctionselect
0:Otherpin-sharedfunctions
1:SSEG12function
Bit5 SEG11EN:SSEG11pinfunctionselect
0:Otherpin-sharedfunctions
1:SSEG11function
Bit4 SEG10EN:SSEG10pinfunctionselect
0:Otherpin-sharedfunctions
1:SSEG10function
Bit3 SEG9EN:SSEG9pinfunctionselect
0:Otherpin-sharedfunctions
1:SSEG9function
Bit2 SEG8EN:SSEG8pinfunctionselect
0:Otherpin-sharedfunctions
1:SSEG8function
Bit1 SEG7EN:SSEG7pinfunctionselect
0:Otherpin-sharedfunctions
1:SSEG7function
Bit0 SEG6EN:SSEG6pinfunctionselect
0:Otherpin-sharedfunctions
1:SSEG6function
