HT66F0175/HT66F0185
A/D Flash MCU with EEPROM
HT66F0175/HT66F0185
A/D Flash MCU with EEPROM
SLCDC3 Register – HT66F0175
Bit 7 6 5 4 3 2 1 0
Name — — SEG19EN SEG18EN SEG17EN SEG16EN SEG15EN SEG14EN
R/W — — R/W R/W R/W R/W R/W R/W
POR — — 0 0 0 0 0 0
Bit7~6 Unimplemented,readas“0”
Bit5 SEG19EN:SSEG19pinfunctionselect
0:Otherpin-sharedfunctions
1:SSEG19function
Bit4 SEG18EN:SSEG18pinfunctionselect
0:Otherpin-sharedfunctions
1:SSEG18function
Bit3 SEG17EN:SSEG17pinfunctionselect
0:Otherpin-sharedfunctions
1:SSEG17function
Bit2 SEG16EN:SSEG16pinfunctionselect
0:Otherpin-sharedfunctions
1:SSEG16function
Bit1 SEG15EN:SSEG15pinfunctionselect
0:Otherpin-sharedfunctions
1:SSEG15function
Bit0 SEG14EN:SSEG14pinfunctionselect
0:Otherpin-sharedfunctions
1:SSEG14function
