Rev. 1.50 154 August 28, 2017 Rev. 1.50 155 August 28, 2017
HT66F0175/HT66F0185
A/D Flash MCU with EEPROM
HT66F0175/HT66F0185
A/D Flash MCU with EEPROM
SLCDC3 Register – HT66F0185
Bit 7 6 5 4 3 2 1 0
Name SEG21EN SEG20EN SEG19EN SEG18EN SEG17EN SEG16EN SEG15EN SEG14EN
R/W R/W R/W R/W R/W R/W R/W R/W R/W
POR 0 0 0 0 0 0 0 0
Bit7 SEG21EN:SSEG21pinfunctionselect
0:Otherpin-sharedfunctions
1:SSEG21function
Bit6 SEG20EN:SSEG20pinfunctionselect
0:Otherpin-sharedfunctions
1:SSEG20function
Bit5 SEG19EN:SSEG19pinfunctionselect
0:Otherpin-sharedfunctions
1:SSEG19function
Bit4 SEG18EN:SSEG18pinfunctionselect
0:Otherpin-sharedfunctions
1:SSEG18function
Bit3 SEG17EN:SSEG17pinfunctionselect
0:Otherpin-sharedfunctions
1:SSEG17function
Bit2 SEG16EN:SSEG16pinfunctionselect
0:Otherpin-sharedfunctions
1:SSEG16function
Bit1 SEG15EN:SSEG15pinfunctionselect
0:Otherpin-sharedfunctions
1:SSEG15function
Bit0 SEG14EN:SSEG14pinfunctionselect
0:Otherpin-sharedfunctions
1:SSEG14function
SLCDC4 Register – HT66F0185
Bit 7 6 5 4 3 2 1 0
Name — — — — — — SEG23EN SEG22EN
R/W — — — — — — R/W R/W
POR — — — — — — 0 0
Bit7~2 Unimplemented,readas“0”
Bit1 SEG23EN:SSEG23pinfunctionselect
0:Otherpin-sharedfunctions
1:SSEG23function
Bit0 SEG22EN:SSEG22pinfunctionselect
0:Otherpin-sharedfunctions
1:SSEG22function
