IFP-75 Series Manual — P/N LS10147-001SK-E:E 4/6/2022 9
Section 1: Introduction
The IFP-75, IFP-75HV, IFP-75B, and IFP-75HVBFire Alarm Control / Communicators are Addressable Fire Alarm Control Systems that
meet the requirements of UL 864 10th Edition Standard.
1.1 Basic System Overview
1.1.1 Hardware Features
• The IFP-75 has one built in signaling line circuit (SLC) that supports 75 SK/IDP detectors and 75 SK/IDP modules or 50 SD devices.
• The IFP-75 is capable of outputting 2.5A of output power during an alarm activation through 2 sets of terminals for the notification
appliance circuits or an auxiliary application. Each circuit is power-limited and can source up to 2.5A during an alarm activation. The
constant auxiliary power load must not exceed 1A for normal standby.
• Built-in dual phone line, digital alarm commu
nicator/transmitter (DACT), IP, or optional cellular technologies.
• Reports events to central station by point or by zone.
• UL Listed for pre-action and deluge releasing systems.
• Two general purpose Form C programmable relays.
• One Form C Trouble Relay.
• Basic system operation can be performed from the onboard, or any remote annunciator.
• Up to 20 user profiles can be programmed, each having custom Access Code, and Main Menu items.
• Can be used with any combination of up to 8 Model RA-100, RA-1000, or RA-2000 Remote LCD Annunciators (sold separately).
• Can be used with Model 5865-3, 5865-4, and 5880 in any combination for a total of eight devices on one control panel. See Section 4.11
and Section 4.12 for additional information on these models.
• Printing of event log available through the Model 5824 serial/parallel printer interface module.
• 125 software zones, 125 Output Groups.
• Add four Notification/Auxiliary power circuits with each 5496 NAC Expander. See note below.
1.1.2 Network System Hardware Features
• The default network setup can contain up to 32- IFP-75 panels connected.
• Network support for up to 32 Sites.
• Each building is referred to as a “site”.
• Panels can be interconnected using CLASS B or CLASS A topology.
• Use the SK-NIC Network Interface Card to create a network. Copper wire or fiber-optic cable panel connectivity can be used within the
same networked System.
• The network architecture provides true peer-to-peer capability allowing network survivability for all hardware that remains operational
in the event of partial system failure.
1.1.3 Software Features
• Advanced smoke detector features:
– Automatic drift compensation
– Maintenance alert region
– Point status meets calibrated smoke test requirements for NFPA 72
• “JumpStart” feature for easy programming
• Non-volatile event history stores 1000 events
• A choice of output patterns available for notification outputs, including Temp 4 along with ANSI 3.41 temporal signal
• Built-in synchronization appliance support for AMSECO, Gentex, Wheelock, or System Sensor
NOTE: All references to IFP-75 within this manual are applicable to the IFP-75, IFP-75B, IFP-75HV, and IFP-75HVB unless specified.
NOTE: Total output power for both circuits must not exceed 2.5A in alarm condition, and total output power for both circuits must not exceed
1.0A for all other activation conditions (i.e. Supervisory, Trouble, etc.).
NOTE: The system can support a maximum of eight intelligent power modules, either the RPS-1000 or 5496, in any combination.
