Page #17 background imageLoading...
Page #17 background image
Accessing the Camera
3
2 Accessing the Camera
This chapter contains the following sections:
Installing the IPC Tool Utility, page 3
Discovering Your Camera on the Network, page 3
Assigning a New IP Address to Your Camera, page 4
Upgrading the Camera’s Firmware, page 5
Accessing the Camera from a Web Browser, page 5
Installing the IPC Tool Utility
To install the IPC Tool utility and create a desktop shortcut:
1. Insert the included Software and Document disc into your PC’s disc drive.
2. Install the IPC Tool utility to your PC. The shortcut is added to the desktop.
Discovering Your Camera on the Network
To discover your network camera(s), open the IPC Tool utility , enter your user name and
password, and then click Connect. Cameras that are online have a green connected icon
next to them. Cameras that are offline have a gray X next to them. To refresh the list, click
Refresh.

Table of Contents

Other manuals for Honeywell HBW4PER2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honeywell HBW4PER2 and is the answer not in the manual?

Honeywell HBW4PER2 Specifications

General IconGeneral
TypeIP security camera
CertificationFCC Part 15B, EN 55032 EN 50130-4 EU: EN 60950-1 North America UL listed to UL/CSA 60950-1 EN 50581
Day/night modeYes
Placement supportedIndoor & outdoor
Connectivity technologyWired
Wi-FiNo
Number of users20 user(s)
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.3af
Ethernet interface typeFast Ethernet
Supported network protocolsIPv4/v6, TCP/IP, UDP, RTP, RTSP, RTCP, HTTP, HTTPS, SSL, FTP, SMTP, DHCP, PPPoE, UPnP, SNMP v2/v3, Bonjour, DNS, DDNS, IEEE 802.1X, QoS, NTP
Ethernet LAN (RJ-45) ports1
Form factorBullet
Mounting typeWall
Product colorBlack, White
International Protection (IP) codeIP66
Bit rate controlConstant Bit Rate (CBR)/Variable Bit Rate (VBR)
Total megapixels4 MP
Gain control typeAuto/Manual
Maximum resolution2688 x 1520 pixels
Video compression formatsH.264, H.264+, H.265, H.265+
Analog signal format systemNTSC, PAL
Supported graphics resolutions352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 2304 x 1296, 2560 x 1440, 2688 x 1520
White balanceAuto, Manual, Natural, Outdoor
Camera shutter typeElectronic
Camera shutter speed1/3 - 1/100000 s
Minimum illumination0.03 lx
Sensor typeCMOS
Optical sensor size1/3 \
Digital zoom16 x
Focal length range2.7 - 13.5 mm
Minimum aperture number1.4
Signal-to-Noise Ratio (SNR)45 dB
LED typeIR
Night vision distance50 m
Power source typeDC, PoE
Power consumption (max)11.74 W
Windows operating systems supportedWindows 7, Windows 7 Enterprise, Windows 7 Home Basic, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Starter, Windows 7 Ultimate
Compatible memory cardsMicroSDHC
Maximum memory card size128 GB
Operating temperature (T-T)-30 - 60 °C
Operating relative humidity (H-H)0 - 95 %
Sustainability certificatesRoHS
Weight and Dimensions IconWeight and Dimensions
Width214.8 mm
Height90.4 mm
Weight685 g
Package weight860 g
