Configuring Video Analytics
49
4.
Select a threshold value, from 1 to 100 for each region. The higher the number, the more
motion will be needed to trigger a motion event. It is recommended that you choose a
sensitivity between 5 to 50.
5.
Click Remove All to delete all motion detection regions. Click Delete to delete the selected
motion detection region.
6.
Click OK to save the configurations. Click Cancel to exit the setup without saving the
changes.
Configuring Camera Tampering Settings
Go to Setup Video Analytics Video DetectionVideo Tampering.
Figure 7-4 Video Tampering
Table 7-2 Tampering Configurations
Parameter Function
Enable
Tamper
Detection
Check to enable video tamper detection.
Enable
Defocus
Detection
Check to enable defocus detection.
Note Defocus Detection is only supported by the following models:
HEW4PER2/HEW2PER2/H4W2PER2/HBW2PER2/H4W8PR2/HBW8PR2.
Alarm
Period
The camera tampering function is activated during the specified period.
See Configuring the Alarm Period on page 47.
You can configure up to six periods per day. Select a date. If you do not
select a date, the current setup will be applied to today only. You can
select All to apply the alarm period to the whole week.
Click OK to save the changes. The system goes back to the video
tampering interface. Click Save to exit.
Record If Record is enabled, a camera tampering event can activate recording.
Record
Delay
The system will wait for the specified time before it begins recording. Select
from 10s to 300s.
Send Email When enabled, the system sends an email alert when an alarm occurs.

Table of Contents

Other manuals for Honeywell HBW4PER2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honeywell HBW4PER2 and is the answer not in the manual?

Honeywell HBW4PER2 Specifications

General IconGeneral
TypeIP security camera
CertificationFCC Part 15B, EN 55032 EN 50130-4 EU: EN 60950-1 North America UL listed to UL/CSA 60950-1 EN 50581
Day/night modeYes
Placement supportedIndoor & outdoor
Connectivity technologyWired
Wi-FiNo
Number of users20 user(s)
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.3af
Ethernet interface typeFast Ethernet
Supported network protocolsIPv4/v6, TCP/IP, UDP, RTP, RTSP, RTCP, HTTP, HTTPS, SSL, FTP, SMTP, DHCP, PPPoE, UPnP, SNMP v2/v3, Bonjour, DNS, DDNS, IEEE 802.1X, QoS, NTP
Ethernet LAN (RJ-45) ports1
Form factorBullet
Mounting typeWall
Product colorBlack, White
International Protection (IP) codeIP66
Bit rate controlConstant Bit Rate (CBR)/Variable Bit Rate (VBR)
Total megapixels4 MP
Gain control typeAuto/Manual
Maximum resolution2688 x 1520 pixels
Video compression formatsH.264, H.264+, H.265, H.265+
Analog signal format systemNTSC, PAL
Supported graphics resolutions352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 2304 x 1296, 2560 x 1440, 2688 x 1520
White balanceAuto, Manual, Natural, Outdoor
Camera shutter typeElectronic
Camera shutter speed1/3 - 1/100000 s
Minimum illumination0.03 lx
Sensor typeCMOS
Optical sensor size1/3 \
Digital zoom16 x
Focal length range2.7 - 13.5 mm
Minimum aperture number1.4
Signal-to-Noise Ratio (SNR)45 dB
LED typeIR
Night vision distance50 m
Power source typeDC, PoE
Power consumption (max)11.74 W
Windows operating systems supportedWindows 7, Windows 7 Enterprise, Windows 7 Home Basic, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Starter, Windows 7 Ultimate
Compatible memory cardsMicroSDHC
Maximum memory card size128 GB
Operating temperature (T-T)-30 - 60 °C
Operating relative humidity (H-H)0 - 95 %
Sustainability certificatesRoHS
Weight and Dimensions IconWeight and Dimensions
Width214.8 mm
Height90.4 mm
Weight685 g
Package weight860 g
