Page #38 background image
Performance Series IP Camera Software Configuration Guide
24
Auto: Auto white balance is on. The system automatically adjusts the color temperature to
ensure that the video color is correct.
Natural: White balance is optimized for natural lighting.
Street Lamp: White balance is optimized for yellow-tinted lighting.
Outdoor: White balance is optimized for outdoor environments.
Manual: Red gain and blue gain values are set by the user. The value ranges from 0 to 100.
D&N Mode
In the D&N Mode field, you can set the day and night mode, sensitivity, and delay time.
By default, the camera automatically outputs color video or black-and-white video depending
on the amount of light in the scene. To output only color video, set Mode to Color. To output
only black-and-white video, set Mode to Black & White.
Sensitivity
Adjusts the sensitivity threshold at which the camera switches from Color to Black & White
mode. Set to Low, Medium (default), or High.
Note Available only when Day & Night is set to Auto.
Delay
Adjusts the delay value of the switch from Color to Black & White mode. The value ranges
from 2 to 10. The default value is 6.
Note Available only when Day & Night is set to Auto.
IR Light
In the IR Light field, you can set the infrared LED mode and other settings. Set Mode to
Manual, Smart IR, or OFF.
Manual: IR near and far distance brightness are set by the user. The value ranges from 0 to
100.
Smart IR: IR settings are adjusted automatically to prevent overexposure or underexposure.
OFF: IR Light is off.
Profile Management
Go to Setup Camera Setup Properties Profile Management.
After you have configured the camera properties for each profile (Normal, Day, Night), you can
set the profile(s) that you want the system to use.

Table of Contents

Other manuals for Honeywell HBW4PER2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honeywell HBW4PER2 and is the answer not in the manual?

Honeywell HBW4PER2 Specifications

General IconGeneral
TypeIP security camera
CertificationFCC Part 15B, EN 55032 EN 50130-4 EU: EN 60950-1 North America UL listed to UL/CSA 60950-1 EN 50581
Day/night modeYes
Placement supportedIndoor & outdoor
Connectivity technologyWired
Wi-FiNo
Number of users20 user(s)
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.3af
Ethernet interface typeFast Ethernet
Supported network protocolsIPv4/v6, TCP/IP, UDP, RTP, RTSP, RTCP, HTTP, HTTPS, SSL, FTP, SMTP, DHCP, PPPoE, UPnP, SNMP v2/v3, Bonjour, DNS, DDNS, IEEE 802.1X, QoS, NTP
Ethernet LAN (RJ-45) ports1
Form factorBullet
Mounting typeWall
Product colorBlack, White
International Protection (IP) codeIP66
Bit rate controlConstant Bit Rate (CBR)/Variable Bit Rate (VBR)
Total megapixels4 MP
Gain control typeAuto/Manual
Maximum resolution2688 x 1520 pixels
Video compression formatsH.264, H.264+, H.265, H.265+
Analog signal format systemNTSC, PAL
Supported graphics resolutions352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 2304 x 1296, 2560 x 1440, 2688 x 1520
White balanceAuto, Manual, Natural, Outdoor
Camera shutter typeElectronic
Camera shutter speed1/3 - 1/100000 s
Minimum illumination0.03 lx
Sensor typeCMOS
Optical sensor size1/3 \
Digital zoom16 x
Focal length range2.7 - 13.5 mm
Minimum aperture number1.4
Signal-to-Noise Ratio (SNR)45 dB
LED typeIR
Night vision distance50 m
Power source typeDC, PoE
Power consumption (max)11.74 W
Windows operating systems supportedWindows 7, Windows 7 Enterprise, Windows 7 Home Basic, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Starter, Windows 7 Ultimate
Compatible memory cardsMicroSDHC
Maximum memory card size128 GB
Operating temperature (T-T)-30 - 60 °C
Operating relative humidity (H-H)0 - 95 %
Sustainability certificatesRoHS
Weight and Dimensions IconWeight and Dimensions
Width214.8 mm
Height90.4 mm
Weight685 g
Package weight860 g
