Performance Series IP Camera Software Configuration Guide
42
Table 6-5 Multicast Configurations
Parameter Function
Enable
Select the check box to enable the multicast function.
Note Main stream and sub stream cannot be used at the same time.
Multicast
Address
The main/sub stream multicast address is 224.1.2.4 and its range is
224.0.0.0 ‒ 239.255.255.255.
Port
Multicast port. The default multicast port of main stream is 40000,
and the default multicast port of sub stream is 40016. The range is
1025 ‒ 65500.
Configuring IEEE802.1X Settings
Go to Setup Network Setup 802.1X.
IEEE802.1X is the access control and authentication protocol for local and metropolitan area
networks. It uses a port-based network access control protocol to restrict unauthorized user
and/or device access to the LAN.
IEEE802.1X supports the client’s ability to manually choose how authentication works for
accessing the LAN or not. IEEE802.1X supports the ability to:
•
authenticate
•
calculate the fee
•
ensure security
•
maintain requirements
Figure 6-11 802.1X
Table 6-6 802.1X Configurations
Parameter Function
Enable Select the check box to enable this function.
Authentication PEAP (protected EAP protocol)
Username
Enter a username to log in. This username is authenticated by
the server.
Password Enter a password.
