Honeywell HC30W45R2 User Manual

12
Honeywell 30 Series IP Cameras User Guide
Figure 12 Login Page
If you are logging in for the first time, you will be prompted to download and install the
plugin. Follow the on-screen instructions to install it. When the installation is complete,
the web client automatically refreshes, and the main page opens.
Logging in Via Google Chrome
1. Type the camera’s IP address in the address bar of Google Chrome and press
Enter on the keyboard. For example, if your camera’s IP address is 192.168.1.108,
you would type https://192.168.1.108.
Note:
Chrome 71 (or later) is supported for H.264 video. Chrome is not supported for
H.265 video.
2. The following window is displayed. Click Advanced.
Figure 13 Safety Problem
3. The following window is displayed. Click Proceed to 192.168.1.108 (unsafe).
Figure 14 Security Certificate Problem

Honeywell HC30W45R2 Specifications

General

Windows operating systems supported	Windows 10, Windows 7
DC-in jack	Yes
Ethernet LAN (RJ-45) ports	1
Lens diameter	2.8 mm
Fixed focal length	2 mm
Maximum aperture number	2
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	12.95 W
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 90 %
Wi-Fi	No
Number of users	10 user(s)
Ethernet interface type	Gigabit Ethernet
Bit rate control	Constant Bit Rate (CBR)
Total megapixels	5 MP
Gain control type	Auto
Maximum resolution	2560 x 1920 pixels
Video formats supported	H.264, H.265
Analog signal format system	NTSC, PAL
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1280 x 960, 1600 x 1200 (UXGA), 2048 x 1536 (QXGA), 2560 x 1920
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	256 GB
Sensor type	CMOS
Optical sensor size	1/2.7 \
White balance	Auto, Manual
Minimum illumination	0.03 lx
IK code	IK10
Form factor	Spherical
Mounting type	Ceiling/wall
Product color	Black, White
Country of origin	Taiwan
International Protection (IP) code	IP66
Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired & Wireless
Maximum operating distance	30 m

Weight and Dimensions

Depth	99.8 mm
Width	133.3 mm
Weight	760 g
Package weight	1100 g
