10 | HD251(X)/HD262(X)/HB273(X) Camera Configuration Guide
www.honeywellvideo.com
Figure 2 MAIN SETUP Menu
Exit Setup Menu
Select the EXIT option (see Figure 2) and press SET to save the current settings and exit
the MAIN SETUP menu.
Lens
1. Move the arrow indicator to LENS using the Up and Down OSD controls on the
Setup menu screen (see Figure 2).
2. Select the desired lens type by pressing the Left or Right OSD controls. Press SET
to open the lens submenu. DC selection = DC auto iris lens.
Note This camera does not have an interchangeable lens. This camera
comes equipped with a DC drive lens.
3. The BRIGHTNESS can be adjusted when DC is selected. The BRIGHTNESS
control range is 1 ~ 100 (see Figure 3).
4. Select the desired SHUTTER mode by pressing the Left or Right OSD controls.
MAIN SETUP
LENS DC
EXPOSURE
WHITE BAL ATW
D-WDR/HSBLC OFF
HD-DNR AUTO
DAY/NIGHT COLOR
SMART-IR OFF
SPECIAL
EXIT
To Next Page
