12 | HD251(X)/HD262(X)/HB273(X) Camera Configuration Guide
www.honeywellvideo.com
AGC (AUTO GAIN CONTROL) A higher gain increases brightness but also increases
any noise. Options are: OFF, LOW, MIDDLE, and HIGH.
SENS-UP This feature increases image clarity and reduces storage requirements for the
camera. At night and/or in dark conditions, the SENS-UP mode can be selected to the
desired value, from x2 ~ x1024. With higher SENS-UP values, more motion blurring will be
visible in the video image.
RETURN Select RETURN to save the changes in the EXPOSURE menu and return to the
SETUP menu.
White Balance
The White Balance function is used to optimize the on-screen colors.
1. Move the arrow indicator to WHITE BAL on the SETUP menu screen using the Up
and Down buttons (see Figure 5).
Figure 5 MAIN SETUP Menu - WHITE BAL Selected
2. Select the desired mode by using the Left or Right OSD controls. There are three
user-selectable White Balance settings available: ATW, AWC, and MANUAL.
ATW (Auto Tracking White Balance) Normal setting; when the color temperature range
is between 1,800°K and 10,500°K (for example, a fluorescent lamp or outdoors).
AWC -> SET To obtain the best results press SET while the camera is focused onto white
paper. If the environment, and/or light source changes, this White Balance mode will
require a re-adjustment. This mode is best suited for scenes with lighting at a constant color
temperature (indoor with consistent lighting at set temperature).
MAIN SETUP
LENS DC
EXPOSURE
WHITE BAL ATW
D-WDR/HSBLC OFF
HD-DNR AUTO
DAY/NIGHT COLOR
SMART-IR OFF
SPECIAL
EXIT
