Configuring the Camera | 17
800-12004V2 - A - 01/2013
Day / Night
Picture can be displayed in either color or black and white.
1. Select DAY / NIGHT using the Up or Down OSD controls on the SETUP menu
screen (see Figure 15).
2. Select the desired Day/Night mode (COLOR, BW, EXT, or AUTO) using the Left and
Right OSD controls.
Figure 15 MAIN SETUP Menu - DAY/NIGHT Selected
COLOR The picture is always displayed in color.
BW The picture is always displayed in black and white. Select BW using the Left and Right
OSD controls and open the menu to activate BURST option.
EXT Day/Night control performed by photocell on the camera board (see Figure 16). This
option is NOT supported by the HD251(X) camera. Only the HD262(X) and HB273(X)
cameras may use this option.
Figure 16 Day/Night EXT Menu
AUTO In this mode, the camera automatically switches to COLOR in normal conditions
and switch to BW mode when ambient illumination is low. This option is NOT supported by
the HB273(X) and HD262(X) cameras. Only the HD251(X) camera may use this option.
Press SET to set the switching time or Day>Night(AGC), Night>Day(AGC) in AUTO mode.
MAIN SETUP
LENS DC
EXPOSURE
WHITE BAL ATW
D-WDR/HSBLC OFF
HD-DNR AUTO
DAY/NIGHT COLOR
SMART-IR OFF
SPECIAL
EXIT
D&N-EXT
BURST OFF
DELAY TIME
4
RETURN
