24 | HD251(X)/HD262(X)/HB273(X) Camera Configuration Guide
www.honeywellvideo.com
SENSITIVITY Use this option to setup the motion sensitivity. You can adjust the motion
sensitivity of a movement from between level 0-30 (see Figure 25).
DISPLAY This option sets how detected motion is displayed on-screen. Select from
ICON, TRACE and TEXT. When set to TEXT, the text of MOTION DETECTION would be
displayed during motion. When ICON is selected, a motion icon is displayed during motion.
When set as TRACE, detected motion will have a colored trace on-screen.
HOLD TIME This option determines how long the motion message appears onscreen
when motion is detected. When setting time of ALARM OUT HIGH, 003 means the message
will appear for 3 seconds.
RETURN Use this option to RETURN to the SPECIAL menu after completing the setup.
Privacy
Use the Privacy option to mask an area that you do not want displayed on the screen.
1. When the SPECIAL menu is displayed, use the Up or Down OSD controls to access
the PRIVACY menu (see Figure 27).
Figure 27 SPECIAL Menu - PRIVACY Submenu Selection
2. Select the Privacy Mask to be used (from 1 to 8) to ON in the PRIVACY menu and
press SET to open the menu for that MASK (see Figure 28).
PRIVACY
MASK1 ON /OFF
MASK2 ON /OFF
~~
MASK8 ON /OFF
RETURN
SPECIAL
CAMERA TITLE OFF
ADJUST
MIRROR OFF
MOTION DET OFF
PRIVACY OFF
SYNC INT
RESOLUTION NORMAL
RESET NO
RETURN
