MANUAL Used for fine White Balance adjustment. Set White Balance first using ATW or
AWC then change to MANUAL and press SET. Increase or decrease the value of M-WR
(Red) and M-WB (Blue) while monitoring the color of the image (see Figure 6). This mode
is best suited for scenes with lighting at a constant color temperature (indoor with
consistent lighting at set temperature).
Figure 6 MANUAL White Balance Menu
D-WDR/HSBLC
This camera uses 3D-DNR, which provides intelligent light level control to overcome even
strong backlight conditions.
1. Move the arrow indicator to D-WDR/HSBLC on the SETUP menu screen using the
Up and Down OSD controls (see Figure 7).
Figure 7 MAIN SETUP Menu - D-WDR/HSBLC Selected
2. Select the desired mode (see the following sections) by using the Left or Right OSD
controls.
OFF BLC function does not operate.
BLC LEVEL Select level from LOW/MID/HIGH.
The BLC ZONE can be set to the desired area by changing the TOP/BOTTOM/LEFT/RIGHT
values (see Figure 8).
WB MANUAL
M-WR
64
M-WB
64
RETURN
MAIN SETUP
LENS DC
EXPOSURE
WHITE BAL ATW
D-WDR/HSBLC OFF
HD-DNR AUTO
DAY/NIGHT COLOR
SMART-IR OFF
SPECIAL
EXIT
To Next Page
