Honeywell HD251(X) User Manual

Configuring the Camera | 23
800-12004V2 - A - 01/2013
Motion Detection
1. When the SPECIAL menu is displayed, use the Up or Down OSD controls to access
the MOTION DETECTION menu (see Figure 25).
Figure 25 SPECIAL Menu - MOTION DETECTION Submenu Selection
2. Configure the Motion Detection settings (see Figure 25) as follows:
ALARM Options are ON and OFF. Select whether motion will activate a visible onscreen
alarm.
AREA ON The area(s) that will be monitored for motion can be set by changing the TOP,
BOTTOM, LEFT and RIGHT values.
a. Select AREA in the MOTION DET menu and press SET to open the MOTION
AREA menu (see Figure 26).
b. In this menu, select the motion detection area to be adjusted (from AREA1 to
AREA4) and press SET to open the AREA1~4 menu.
c. Use the Up, Down, Left and Right OSD controls to change the TOP,
BOTTOM, LEFT and RIGHT values, as needed.
d. Select RETURN and press SET to save the area.
Figure 26 MOTION DETECTION AREA Adjustment

MOTION DET
ALARM ON
AREA 
SENSITIVITY  025
DISPLAY OFF
HOLD TIME  003
RETURN 

SPECIAL
CAMERA TITLE OFF
ADJUST 
MIRROR OFF
MOTION DET OFF
PRIVACY OFF
SYNC INT
RESOLUTION NORMAL
RESET NO
RETURN 

MOTION AREA
AREA1 ON
AREA2 ON
AREA3 ON
AREA4 ON
RETURN 

AREA1~4 ON
TOP  25
BOTTOM  65
LEFT  30
RIGHT  80
RETURN 
