Configuring the Camera | 11
800-12004V2 - A - 01/2013
Figure 3 DC Lens Menu
5. Press SET on RETURN to return to the SETUP menu.
Note SHUTTER: Select SHUTTER using the Up or Down OSD controls, you
can adjust the shutter speed from 1/60, FLK, 1/250 - 1/100,000.
FLK: Select FLK mode to compensate for flickering and color rolling in
fluorescent lit scenes. If FLK mode is selected, the SENS-UP function
is disabled.
Exposure
This function is used to select SENS-UP or Auto gain control.
1. On the Setup menu screen select EXPOSURE by using the Up or Down OSD
controls and press SET (see Figure 4).
Figure 4 MAIN SETUP Menu - EXPOSURE Submenu Selection
2. Select the AGC and SENS-UP options required for your installation.
DC
BRIGHTNESS |........|........| 23
E. SHUTTER 1/60
RETURN
MAIN SETUP
LENS DC
EXPOSURE
WHITE BAL ATW
D-WDR/HSBLC OFF
HD-DNR AUTO
DAY/NIGHT COLOR
SMART-IR OFF
SPECIAL
EXIT
EXPOSURE
AGC HIGH
SENS-UP X16
RETURN
