Honeywell Hyperion 1300G User Manual

7 - 2
Supported Interface Keys
ASCII HEX
IBM AT/XT and
PS/2 Compatibles,
WYSE PC/AT
Supported Keys
NUL 00 Reserved
SOH 01 Enter (KP)
STX 02 Cap Lock
ETX 03 ALT make
EOT 04 ALT break
ENQ 05 CTRL make
ACK 06 CTRL break
BEL 07 CR/Enter
BS 08 Reserved
HT 09 Tab
LF 0A Reserved
VT 0B Tab
FF 0C Delete
CR 0D CR/Enter
SO 0E Insert
SI 0F Escape
DLE 10 F11
DC1 11 Home
DC2 12 Print
DC3 13 Back Space
DC4 14 Back Tab
NAK 15 F12
SYN 16 F1
ETB 17 F2
CAN 18 F3
EM 19 F4
SUB 1A F5
ESC 1B F6
FS 1C F7
GS 1D F8
RS 1E F9
US 1F F10
* IBM 3191/92, 3471/72, 3196/97, 3476/77,
Telex (all models)

Honeywell Hyperion 1300G Specifications

General

Type	Handheld bar code reader
Sensor type	-
Scanner type	1D
Maximum range	0.66 m
Read rate (max)	270 reads/s
Pitch reading angle	-65 - 65 °
Light levels (direct sunlight)	0 - 70000 lx
Cable length	3 m
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	200 mA
Safety	RoHS, CE
Shockproof	Yes
Product color	Black
International Protection (IP) code	IP41
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	112 mm
Width	79 mm
Height	150 mm
Weight	160 g
