2 - 7
Datalogic™ Magellan
®
Bioptic
Aux Port Configuration
Scan the following Plug and Play code to program the scanner for a Datalogic
Magellan bioptic scanner auxiliary port configuration. This bar code sets the
baud rate to 9600 bps and the data format to 8 data bits, no parity, 1 stop bit.
Note: If you are having unexpected results with this programming code, scan
the Activate Defaults bar code on page 1-5 first, then scan the
programming code above.
Wincor Mode A
Scan the following Plug and Play code to program the scanner for Wincor Mode
A mode. This bar code sets the baud rate to 9600 bps and the data format to 8
data bits, odd parity, 1 stop bit.
Note: If you are having unexpected results with this programming code, scan
the Activate Defaults bar code on page 1-5 first, then scan the
programming code above.
Datalogic Magellan Bioptic Settings
