Honeywell Hyperion 1300G User Manual

3 - 6
Presentation Mode
Presentation Mode uses ambient light to detect bar codes. The LEDs are off for
ambient conditions until a change occurs in the scanner’s field of view. Then
the LEDS turn on automatically to read the code. If the light level in the room is
not high enough, Presentation Mode may not work properly.
Continuous Illumination Mode (Manual Trigger only)
If you have several bar codes that are close together, you may wish to have a
continuous aiming beam on in order to properly aim the scanner at one bar
code. Scan the Continuous Illumination On bar code to program the scanner
for this capability. Once you have the aiming beam over the correct bar code,
pull the trigger to read the code. Scan the Continuous Illumination Off bar
code to turn off this feature.
Hands Free Time-Out
The Automatic Trigger and Presentation Modes are referred to as “hands free”
modes. If the scanner’s trigger is pulled when using a hands free mode, the
scanner changes to manual trigger mode. You can set the time the scanner
should remain in manual trigger mode by setting the Hands Free Time-Out.
Once the time-out value is reached, (if there have been no further trigger pulls)
the scanner reverts to the original hands free mode.
Presentation Mode
Continuous Illumination
Mode On
* Continuous Illumination
Mode Off

Honeywell Hyperion 1300G Specifications

General

Type	Handheld bar code reader
Sensor type	-
Scanner type	1D
Maximum range	0.66 m
Read rate (max)	270 reads/s
Pitch reading angle	-65 - 65 °
Light levels (direct sunlight)	0 - 70000 lx
Cable length	3 m
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	200 mA
Safety	RoHS, CE
Shockproof	Yes
Product color	Black
International Protection (IP) code	IP41
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	112 mm
Width	79 mm
Height	150 mm
Weight	160 g
