5 - 4
Interface / Terminal ID Table
Data Format Editor Commands
When working with the Data Format Editor, a virtual cursor is moved along your
input data string. The following commands are used to both move this cursor to
different positions, and to select, replace, and insert data into the final output.
For examples that use the Data Format Editor commands, refer to Data Format
Editor Commands on page 5-4.
Send Commands
Send all characters
F1 Include in the output message all of the characters from the input
message, starting from current cursor position, followed by an insert
character.
Syntax = F1xx
where xx stands for the insert character’s hex
value for the CP1252 character. Refer to the ASCII Conversion Chart
(Code Page 1252), beginning on page A-2 for decimal, hex and
character codes.
Send a number of characters
F2 Include in the output message a number of characters followed by an
insert character. Start from the current cursor position and continue for
“nn” characters or through the last character in the input message,
followed by character “xx.”
Syntax = F2nnxx
where nn stands for the
numeric value (00-99) for the number of characters, and xx stands for
the the insert character’s hex value for the CP1252 character. Refer to
the ASCII Conversion Chart (Code Page 1252), beginning on page A-
2 for decimal, hex and character codes.
Terminal Model(s) Terminal ID
USB PC keyboard (HID)
124
Mac Keyboard
125
PC Keyboard (Japanese)
134
Serial (COM driver required)
130
HID POS
131
USB SurePOS Handheld
128
USB SurePOS Tabletop
129
Serial RS232 TTL
000
RS232 True
000
RS485 (IBM-HHBCR 1+2, 46xx)
051
Keyboard PS2 compatibles
003
AT c omp atibles
002
