Honeywell Hyperion 1300G User Manual

9 - 16
Interleaved 2 of 5
Check Digit
*No Check Char. I25CK20 6-12
Validate, But Don’t
Trans mit
I25CK21 6-12
Validate, and Transmit I25CK22 6-12
Interleaved 2 of 5 Mes-
sage Length
Minimum (2 - 80) *4 I25MIN## 6-12
Maximum (2 - 80) *80 I25MAX## 6-12
Code 93 Default All Code 93
Settings
C93DFT 6-13
Code 93 Off C93ENA0 6-13
*On C93ENA1 6-13
Code 93 Message
Length
Minimum (0 - 80) *0 C93MIN## 6-13
Maximum (0 - 80) *80 C93MAX## 6-13
Straight 2 of 5 Indus-
trial
Default All Straight 2 of
5
Settings
R25DFT 6-15
Straight 2 of 5 Indus-
trial
Off R25ENA0 6-15
*On R25ENA1 6-15
Straight 2 of 5 Indus-
trial Message Length
Minimum (1 - 48) *4 R25MIN## 6-15
Maximum (1 - 48) *48 R25MAX## 6-15
Straight 2 of 5 IATA Default All Straight 2 of
5 IATA
Settings
A25DFT 6-16
Straight 2 of 5 IATA *Off A25ENA0 6-16
On A25ENA1 6-16
Straight 2 of 5 IATA
Message Length
Minimum (1 - 48) *4 A25MIN## 6-16
Maximum (1 - 48) *48 A25MAX## 6-16
Matrix 2 of 5 Default All Matrix 2 of
5
Settings
X25DFT 6-17
Matrix 2 of 5 *Off X25ENA0 6-17
On X25ENA1 6-17
Selection
Setting
* Indicates default
Serial
Command
# Indicates a
numeric entry
Page

Honeywell Hyperion 1300G Specifications

General

Type	Handheld bar code reader
Sensor type	-
Scanner type	1D
Maximum range	0.66 m
Read rate (max)	270 reads/s
Pitch reading angle	-65 - 65 °
Light levels (direct sunlight)	0 - 70000 lx
Cable length	3 m
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	200 mA
Safety	RoHS, CE
Shockproof	Yes
Product color	Black
International Protection (IP) code	IP41
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	112 mm
Width	79 mm
Height	150 mm
Weight	160 g
