Honeywell Hyperion 1300G User Manual

9 - 21
GS1 DataBar
Expanded
Default All GS1 Data-
Bar
Expanded Settings
RSEDFT 6-41
GS1 DataBar
Expanded
Off RSEENA0 6-41
*On RSEENA1 6-41
GS1 DataBar
Expanded Msg.
Length
Minimum (4 - 74) *4 RSEMIN## 6-41
Maximum (4 - 74) *74 RSEMAX## 6-41
China Post Code Default All China Post
Code Settings
CPCDFT 6-42
China Post Code *Off CPCENA0 6-42
On CPCENA1 6-42
China Post Code Msg.
Length
Minimum (2 - 80) *4 CPCMIN## 6-42
Maximum (2 - 80) *80 CPCMAX## 6-42
Korea Post Code Default All Korea Post
Code Settings
CPCDFT 6-43
Korea Post Code *Off CPCENA0 6-43
On CPCENA1 6-43
Korea Post Code Msg.
Length
Minimum (2 - 80) *4 CPCMIN## 6-43
Maximum (2 - 80) *80 CPCMAX## 6-43
Codablock F Default All Codablock
F Settings
CBFDFT 6-44
Codablock F *Off CBFENA0 6-44
On CBFENA1 6-44
Codablock F Msg.
Length
Minimum (1 - 2048) *1 CBFMIN#### 6-44
Maximum (1 - 2048)
*2048
CBFMAX#### 6-44
Code 49 Default All Code 49
Settings
C49DFT 6-45
Code 49 * Off C49ENA0 6-45
On C49ENA1 6-45
Code 49 Minimum (1 - 81) *1 C49MIN## 6-45
Maximum (1 - 81) *81 C49MAX## 6-45
Selection
Setting
* Indicates default
Serial
Command
# Indicates a
numeric entry
Page

Honeywell Hyperion 1300G Specifications

General

Type	Handheld bar code reader
Sensor type	-
Scanner type	1D
Maximum range	0.66 m
Read rate (max)	270 reads/s
Pitch reading angle	-65 - 65 °
Light levels (direct sunlight)	0 - 70000 lx
Cable length	3 m
Standard interfaces	USB
Connectivity technology	Wired
Input voltage	5 V
Power consumption	200 mA
Safety	RoHS, CE
Shockproof	Yes
Product color	Black
International Protection (IP) code	IP41
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	112 mm
Width	79 mm
Height	150 mm
Weight	160 g
