MC Toolkit Software with Honeywell HART Transmitters
Release 3 34-ST-25-20 MC Toolkit User Manual 47
9/06
Honeywell HART Main Menu Procedures
Local
Meter
Local Meter refers to a
meter installed integrally in
an ST 3000 transmitter, or to
a remote-mounted meter that
is associated with the
ST 3000 transmitter.
Meter Units - Engineering
Units associated with the
Local Meter
For more information, refer
to the user manuals(s) for
the transmitter and/or for the
Remote Meter Assembly
(RMA 3000).
Sensor
(STT25H
Sensor Type - Select from list. (See Reference Data section
for more information.)
Line Filter - Select: 50 Hz/60 Hz.
RTD Wire - If the sensor is an RTD type, this field indicates
whether it is a 3-wire or a 4-wire RTD.
CJ Mode Comp. (STT25H) - (Cold Junction Mode
Compensation); select Internal CJ/External CJ.
