CALCULATING THE POWER SUPPLY FOR
COMPONENTS
2.1 Power module specifications
The following table lists the power specifications for all the modules within the PLC.
Table 20: Power specifications
Module Types of Model Current consumption (mA)
Non redundant CPU Module 2MLI-CPUU 960
2MLI-CPUH 960
2MLI-CPUS 940
2MLI-CPUS/P 940
Redundant CPU Module 2MLR-CPUH/T 980
2MLR-CPUH/F 1310
Expansion Driver Module 2MLR-DBST 550
2MLR-DBSF 550
2MLR-DBSH 550
2MLR-DBDT 550
2MLR-DBDH 550
2MLR-DBDF 550
Digital Input Module (DC 24V) 2MLI-D21A 20
2MLI-D22A 30
2MLI-D22B 30
2MLI-D24A 50
2MLI-D24B 50
2MLI-D28A 60
2MLI-D28B 60
- 17 -
