Chapter 1 - Masterlogic components
Item Type Description
Snet 2MLL-C22A Serial communication, RS-232C 2channels
2MLL-C42A Serial communication, RS-422 2channels
2MLL-CH2A Serial communication, RS-232C/RS-422 (1ch each)
Dnet 2MLL-DMEA DeviceNet interface module
FEnet 2MLL-EFMT Fast Ethernet, 100/100Mbps, RJ-45 (Electric)
2MLL-EFMF Fast Ethernet, 100/100Mbps, SC Type (Fiber Optic)
Pnet 2MLL-PMEA Profibus, master, 12Mbps, DP Standard
2MLL-PSEA Profibus slave interface
2MLL-PSRA Profibus remote interface, DP standard
ATTENTION
The 2MLL-PSRA must be installed only on ML200-IEC CPU bases.
1.4 Types of base
The ML200-IEC and ML200R comprises of main base and expansion base.
ML200-IEC Main base
The main base of ML200-IEC consists of the power module, CPU module, I/O module, special module,
and the communication module.
The following table lists the types of bases for ML200-IEC.
Table 9: Types of bases for ML200-IEC
PLC Types Part Number Description
2MLI-CPUH
2MLI-CPUS
2MLI-CPUU
2MLB-M04A Main base 4 slot
2MLB-M06A Main base 6 slot
2MLB-M08A Main base 8 slot
2MLB-M12A Main base 12 slot
2MLI-CPUS/P
2MLR-M06P Main base 6 slot
2MLR-E08P Main base 8 slot
2MLR-E12P Main base 12 slot
- 8 -
