Figure 13: ML200-IEC architecture
ATTENTION
l The base has its base number as ‘0’ and the expansion base has a switch to set the base
number.
l The module starts operating once the the module type and I/O parameter are set using
SoftMaster and the correct module type is mounted on the base.
l 2MLI CPUS/P does not support expansion base.
- 34 -
