Chapter 1 - Masterlogic components
Index Part Function
1 Base attached
guide hole
For attaching the main base to the panel in the control
panel.
2 Power module
connector
For installation of the Power supply module.
3 CPU module
connector
For installation of the CPU module (2 slots).
4 Module built-in
connector
For installation of the communication modules.
5 FG terminal The ground terminal connected to the shielded pattern of
the PCB board.
ML200R Expansion base
ML200R input/output base communication includes expansion base and expansion driver modules.
The following are the two types of IO link topology for ML200R.
l Expansion base without dual IO link redundancy
l Expansion base with dual IO link redundancy
Expansion base without dual IO link redundancy
The expansion base of ML200R consists of the power module, expansion driver module, I/O module,
special module, and the communication module. (Ethernet module is not allowed in the expansion
base).
The following table provides details about the expansion base and expansion driver modules for
ML200R.
Table 15: Expansion base and expansion driver module for ML200R
PLC types Part number Description
ML200R 2MLR-E08P Expansion base 8 slot
2MLR-E12P Expansion base 12 slot
2MLR-DBSF Expansion driver module FO
2MLR-DBST Expansion driver module TP
2MLR-DBSH Expansion driver module TP/FO
The following image illustrates the expansion base of ML200R, which does not support dual I/O link
redundancy.
