Honeywell ML200 Series User Manual

Chapter 4 - Troubleshooting
Code Error Causes
Measures
Restart mode after the
measure.
Operation
Status
LED
Status
Diagnostic
Timing
44 Use of Timer
Index error
Modify the timer index
program, reload, and
start.
STOP
(RUN)
RUN:
OnERR :
On
When scan
ends.
50 Error of external
device is detected
by a user
program during
operation
Repair a fault device by
referring to error
detection flag of external
device and restart
(according to
parameter).
STOP
(RUN)
ERR : On
(P.S. :
On)
When scan
ends.
60 E_STOP function
execution
Eliminate the causes of
error operating E_STOP
function in the program
and turn it on again.
STOP RUN:
OnERR :
On
When
program is
executed.
101 CPU position
error
CPU is installed at
wrong position. Position
the CPU correctly.
STOP S101 Turn it on.
102 Duplicated CPU
ID error
Set the A/B side
switches of master CPU
and standby CPU
differently.
STOP S102 Turn it on.
103 Base abnormal
error
Configure the expansion
cable as ring topology
and position the
detached base correctly.
For information of
detached base, refer to
the CPU error log.
STOP,
RUN
E103 Execute
program.
104 System
configuration
error
Check for dual IO link
redundancy
configuration and ring
topology.
l Check redundancy
drive module station
number.
l Check the version of
the operating system
of the expansion drive
module and the
expansion manager.
STOP E104 When the
scan ends,
turn it on.
- 59 -
