NFS2-3030 Programming Manual — P/N 52545:K1 03/20/2012 59
Point Program Program
Figure 3.48 Logic Zone Programming Menu Screen
Soft Keys
EDIT EQUATION: Press to proceed to the edit screen to add or
edit a logic equation.
NEXT/PREVIOUS EQUATI
ON: Press to view the next or previous logic equation.
Edit Logic Equation
This screen displays when the EDIT EQUATION soft key is pressed on the Logic Zone.
Programming Menu
Figure 3.49 Edit Logic Equation Screen
The cursor will be present in the equati
on, and can be moved by pressing the left/right arrow keys
on the keyboard. To add or delete information, use the INS/OVR soft key function described
below. Use the keypad to type in an equation. The ADD POINT/ZONE and ADD LOGIC
FUNCTION soft keys may be used to facilitate creating a logic equation; however, commas must be
added by using the keypad.
LOGIC ZONE PROGRAMMING MENU
LOGIC ZONE ZLxxxx
AUTOMATIC OFF
AND(Z20,OR(L2D159,L2D14))
EDIT EQUATION
NEXT EQUATION ACCEPT
PREVIOUS EQUATION BACK
LOGIC ZONE PROGRAMMING MENU
LOGIC ZONE ZLxxxx
AUTOMATIC OFF INS/OVR
AND(Z20,OR(L2D159,L2D14))
INSERT
ADD POINT/ZONE DELETE EQUATION
ADD LOGIC FUNCTION ACCEPT
ADD TIME/DATE BACK
INSERT or OVERWRITE displays here.
