60 NFS2-3030 Programming Manual — P/N 52545:K1 03/20/2012
Program Point Program
Soft Keys
INS/OVR: Press to to
ggle between insert and overwrite. Stop at the appropriate mode, which
displays in line 8 of the screen. Insert will add information to the equation, overwrite will write
over information already in the equation.
ADD POINT/ZONE: Press to proceed to the
Add Point/Zone screen. This screen is an alternative
to typing in the information at this screen; it provides point and zone formats that make it less likely
for typographical errors to occur.
ADD LOGIC FUNCTION: Press
to proceed to the Add Logic Function screen. This screen is an
alternative to typing in the information at this screen; it provides logic function formats that make it
less likely for typographical errors to occur.
ADD TIME/DATE: Press to proceed to the Add
Time/Date screen.
DELETE EQUATION: Press to delete
the entire equation.
ACCEPT: Press to
save changes made on this screen and return to the previous screen.
Add Point/ Zone
Figure 3.50 Add Logic Point/Zone Screen
The cursor will be present in the logic equation. Place
it, using the arrow keys on the keyboard, at
the place where the additional point should be inserted.
Soft Keys
POINT SELECT: Pr
ess to scroll through the list of possible formats (detector, module, etc.). Stop
at the desired format. Type in the address for the additional point.
ACCEPT: Press to
insert the point into the equation where the cursor is blinking, and to return to
the previous screen.
NEXT/PREVIOUS POINT: Press thes
e soft keys to scroll forward or backward from the
displayed point to the next installed point.
NOTE: When the ACCEPT soft key is pressed to save an equation, the panel checks the
equation for errors. If there is an error in the equation, the previous screen will not appear, and the
cursor will appear at the error point. Correct the equation, and re-press the ACCEPT soft key.
LOGIC ZONE PROGRAMMING MENU
LOGIC ZONE ZLxxxx
AUTOMATIC OFF
AND(Z20,OR(L2D159,L2D14))
POINT SELECT:
L01D043 (DETECTOR)
NEXT POINT ACCEPT
PREVIOUS POINT BACK
