Honeywell NOTIFIER ID61 User Manual

ID61/62 Series Panel - Operating Manual
Operator Actions at Panel
18997-458-000-8, Issue 8
January 2010
4.7 Numeric Keys
When using any numeric key, each operation is confirmed
by a sharp audible bleep.
At Access Level 1, the numeric buttons have NO function
until an alarm condition occurs. The alarm condition
enables the ‘
2
’ and ‘
8
’ buttons, allowing the user to
view each alarm in turn.
At Access Level 2 the ‘
2
/
8
’ function remains identical
to the Level 1 function. The ‘
4
’ (cancel), ‘
5
’ (confirm),
‘
6
’ (go to next option) pushbuttons are enabled.
Numeric entry (used in conjunction with the ‘
0..9
’ [shift]
button) is also enabled.
a. Use the ‘
2
’ and ‘
8
’ buttons to scroll through fire
alarms, fault conditions, and warning conditions or to
view the ‘More’ menu list when available.
b. Press the ‘
5
’ button to confirm an option.
c. Press the ‘
0..9
’ (Shift) button to enable number entry.
Following the input of a number (approx. 1 second
later) a second audible bleep indicates that number
entry is no longer enabled.
d. When an internal printer is fitted, press the un-shifted
‘
0
’ button to feed the printer paper - one press of
the ‘
0
’ button advances the paper by one line.
4.7.1 Cancellation/Termination Button
To cancel or terminate configuration data entry, press the
‘
4
’ button. The LCD returns to the previous menu.
To cancel access rights, press the ‘
4
’ button until the
‘Status: NORMAL’ message is displayed.
4.7.2 Level 2 Options Menu Button
Operating the ‘ ’ button enables the Level 2 menu and
prompts for the entry of an appropriate access code, as
described in Section 4.1.3 Access Codes.
Pressing the menu button toggles between the panel
status and user menus.
Press and hold the ‘
0..9
’
(Shift) pushbutton while
entering numbers.
0..9
4
