ID61/62 Series Panels - Operating Manual
Introduction
2997-458-000-8, Issue 8
January 2010
1.2.1 Device Type Abbreviations
Throughout this manual the panel may refer to devices
by an abbreviated name. The following table lists the
device type abbreviation and its description.
1.3 Cleaning
The panel case may be cleaned periodically by wiping
with a soft, damp lint-free cloth.
Do not use solvents.
Abbreviation Type Description
AUX Plant Warning Input
AVR Advanced VIEW™ Reference
AVS Advanced VIEW™ Sensor
CTL Monitored (Relay Type) Output
DKM Tri-state MCP (not supported in UK)
ESM Extinguishant System
ESO Monitored Extinguishing System Output
EST Extinguishant Monitor System Trigger
ION Ionisation Smoke Detector
IRL Immediate Release Input
LBM Loop Booster Module
MCP Manual Call Point
MLT Advanced Multi Sensor
MNS Monitor module (no short-circuit)
MON Fire Alarm Monitor Input
MRL Manual Release Input
M-CZ Conventional Interface input (OPAL)
OPT Optical/Photo-electric Smoke Detector
OPX Optiplex Multi-sensor
RLY Unmonitored (Relay Type) or O/C Outputs
SM4 SMART muti-criteria sensor
SDR Monitored (Sounder Type) Output
SDH Monitored (Sounder Type) Output - high load
SM2 SMART 2 Multi-criteria Sensor (OPAL)
SM3 SMART 3 Multi-criteria Sensor
SM4 SMART 4 Multi-criteria Sensor
STRB Strobe (OPAL)
TMP Temperature Detector
