Honeywell ST 3000 Installation Guide

5.1 Wiring Diagrams and Dimension Drawings, Continued
Dimension Drawings - Series 100 and Series 900, Continued
Transmitter Type and Table Mounting Drawing
Key Number Selections
Angle Bracket (MB), (SB) Flat Bracket (FB) Number
Vertical
Pipe
Horizontal
Pipe
Vertical
Pipe
Horizontal
Pipe
Gauge and Absolute Pressure
STG944, STG974
See Key Number
51500411 51500409
⇐
Column
51500410 51500408
⇐
STG140, STG170, STG180,
See Key Number
51500362 51500360
⇐
STA122, STA140
Column
5500361 51500359
⇐
STA922, STA940 51500366 515004364
⇐
51500365 51500363
⇐
STG14L, STG17L, STG18L 51500373 51500371
⇐
51500372 51500370
⇐
STG90L, STG94L, STG97L, 51500377 51500375
⇐
STG98L 51500376 51500374
⇐
STG14T (High Temperature) ½-inch NPT 51404482
Flush Sanitary
Seal
51404484
Continued on next page
2/05 ST 3000 Release 300 Installation Guide
47

Honeywell ST 3000 Specifications

General

Manufacturer	Honeywell
Category	Transmitter
Stability	±0.01% of URL per year
Operating Temperature	-40 to 85°C (-40 to 185°F)
Communication Protocol	HART
Housing Material	Aluminum or Stainless Steel
Enclosure Rating	IP66/67, NEMA 4X
Measurement Type	Gauge, Absolute, Differential
Output Signal	4-20 mA, HART
Process Temperature	-40 to 121°C (-40 to 250°F)
Hazardous Area Approvals	FM, CSA, ATEX, IECEx
Process Connection	1/2" NPT
Material	316L Stainless Steel, Hastelloy C
