HP 5800-48G User Manual

94
NOTE:
USB devices from different vendors vary in compatibility and driver. HP does not guarantee correct
operation of USB devices from other vendors on the switch. If a USB device does not operate correctly on
the switch, replace it with one from another vendor.
10/100/1000Base-T Ethernet port
All 5820X and 5800 switches but the 5800-24G-SFP (1 slot) and the 5800-24G-SFP TAA (1 slot), have
10/100/1000Base -T Ethernet ports.
Table 15 10/100/1000Base-T Ethernet port specifications
Item S
p
ecification
Connector type RJ-45
Interface attributes
• 10 Mbps, full duplex
• 100 Mbps, full duplex
• 1000 Mbps, full duplex
• MDI/MDI-X, auto-sensing
Max transmission
distance
100 m (328.08 ft)
Transmission medium Category-5 (or above) twisted pair cable
Standards IEEE 802.3i, 802.3u, 802.3ab
100/1000Base-X SFP port
The 5800-48G-PoE+ (2 slots), 5800-48G-PoE+ TAA (2 slots), 5800-24G-SFP (1 slot), and
5800-24G-SFP TAA (1 slot) switches have 100/1000Base-X SFP ports, and you can install the 1000
Mbps SFP transceiver modules in Table 16 and the 1
00 Mbps SFP modules in Table 17 in the ports.
Table 16 1000 Mbps SFP transceiver modules available for the 100/1000 Base-X SFP ports
Product
Code
Module description
Central
wavelength
(nm)
Cable/fiber
diameter
(μm)
Multimode
fiber modal
bandwidth
(MHz
×
km)
Max transmission
distance
JD089B
HP X120 1G SFP
RJ45 T transceiver
N/A
Category-5
twisted pair
N/A 100 m (328.08 ft)
JD118B
HP X120 1G SFP LC
SX transceiver
850
50/125
500 550 m (1804.46 ft)
400 500 m (1640.42 ft)
62.5/125
200 275 m (902.23 ft)
160 220 m (721.78 ft)
JD119B
HP X120 1G SFP LC
LX transceiver
1310 9/125 N/A 10 km (6.21 miles)
