Chassis Dimensions (H ×
W ×
D)
Wei
g
ht
5820AF-24XG
43.6 × 440 × 660 mm
(1.72 × 17.32 × 25.98 in)
≤ 11.2 kg (24.69 lb)
• 5820X-24XG-SFP+
• 5820X-24XG-SFP+ TAA
43.6 × 440 × 427 mm
(1.72 × 17.32 × 16.81 in)
≤ 8.5 kg (18.74 lb)
• 5820X-14XG-SFP+ (2 slots)
• 5820X-14XG-SFP+ TAA (2 slots)
86 × 440 × 467 mm
(3.39 × 17.32 × 18.39 in)
≤ 17 kg (37.48 lb)
Ports and slots (5800 switches)
Item
5800-48
G-PoE+
(2
slots)/58
00-48G-
PoE+
TAA (2
slots)
5800-48
G (1
slot)/580
0-48G
TAA (1
slot)
5800-48
G-PoE+
(1
slot)/580
0-48G-Po
E+ TAA (1
slot)
5800AF-
48G
5800-24
G/5800-
24G TAA
5800-24
G-PoE+/
5800-24
G-PoE+T
AA
5800-24
G-SFP (1
slot)/580
0-24G-SF
P TAA (1
slot)
Console ports
1, front
panel
1, covered
by the logo
plate on
the front
panel
1, covered
by the
logo plate
on the
front panel
1, rear
panel
1, front
panel
1, front
panel
1, covered
by the
logo plate
on the
front panel
Management
Ethernet ports
N/A N/A N/A
1, on the
rear panel
N/A N/A
1, on the
rear panel
USB ports (full
speed)
1, front
panel
1, covered
by the logo
plate on
the front
panel
1, covered
by the
logo plate
on the
front panel
1, rear
panel
1, front
panel
1, front
panel
1, covered
by the
logo plate
on the
front panel
10/100/10
00Base-T
Ethernet ports
48, PoE 48 48, PoE 48 24 24, PoE N/A
100/1000B
ase-X SFP
ports
4 N/A N/A N/A N/A N/A 24
SFP+ ports N/A 4 4 6 4 4 4
Expansion
interface card
slots
2, front
panel
1, rear
panel
1, rear
panel
N/A
1, rear
panel
1, rear
panel
1, front
panel
OAP card
slots
1 N/A N/A N/A N/A N/A N/A
Fan tray slots
1, hot
swapping
N/A
(Built-in
fans are
used.)
N/A
(Built-in
fans are
used.)
2, hot
swapping
N/A
(Built-in
fans are
used.)
N/A
(Built-in
fans are
used.)
1, hot
swapping
