Product
Code
Module
description
Central
wavelength
(nm)
Fiber
diameter
(μm)
Multimode
fiber modal
bandwidth
(MHz × km)
Max transmission distance
JD094B
HP X130 10G
SFP+ LC LR
transceiver
1310 9/125 N/A 10 km (6.21 miles)
Table 20 SFP+ cables available for the SFP+ ports
Product code Cable descri
p
tion
Cable len
g
th
JD095C HP X240 10G SFP+ SFP+ 0.65m DA Cable 0.65 m (2.13 ft)
JD096C HP X240 10G SFP+ SFP+ 1.2m DA Cable 1.2 m (3.94 ft)
JD097C HP X240 10G SFP+ SFP+ 3m DA Cable 3 m (9.84 ft)
JG081C HP X240 10G SFP+ SFP+ 5m DA Cable 5 m (16.40 ft)
JC784C HP X240 10G SFP+ SFP+ 7m Direct Attach Copper Cable 7 m (22.97 ft)
NOTE:
• To guarantee the functionality of the SFP+ ports, use only HP SFP or SFP+ transceiver modules.
• The SFP and SFP+ transceiver modules available for this switch series are subject to chan
g
e over time.
For the most up-to-date list of SFP transceiver modules, consult your HP sales representative or technical
support engineer.
• For the SFP transceiver module specifications, see
HP A-Series Switches Transceiver Modules User
Guide
.
The SFP+ cables available for the 5800 and 5820X switches are 10 Gbps SFP+ Cu cables, as shown
in Figure 93.
Figure 93 SFP+ cable
(1) Connector (2) Pull latch
LEDs
Table 21 shows the availability of each LED on a 5800 or 5820X switch.
