111
Figure 99 Airflow through the chassis (with LSWM1FANSCB fan trays)
(1) Power supply air vents (2) Fan tray air vents
(3) Network port-side air vents
IMPORTANT:
The chassis and the power supplies use separate air aisles. Make sure that both aisles are not blocked.
5800-24G/5800-24G TAA
Figure 100 shows the airflow design for the 5800-24G and 5800-24G TAA switches. Cool air flows in
from the left side of the chassis, circulates through the chassis and the interface card, and exhausts out the
right side of the chassis.
22
3
11
