Figure 3 2U cable management bracket and mounting bracket kit
(1) Cable management bracket (2) Mounting bracket
Rack mounting rail kit
The 5800AF-48G and 5820AF-24XG switches come with a pair of chassis rails and a pair of slide rails.
Figure 4 Rack mounting rail kit
(1) Chassis rail (2) Slide rail
Rack-mounting procedures at a glance
You can install the switch in a 19-inch rack by using different rack mounting positions. Use Table 6 to
identify the rack-mounting procedure for your switch.
