107
Figure 95 Airflow through the upper half of the chassis
(1) Outlet air vents in the fan tray panel
(2) Front panel
(3) Side inlet air vents
5800-48G (1 slot)/5800-48G TAA (1 slot)
Figure 96 shows the airflow design for the 5800-48G (1 slot) and 5800-48G TAA (1 slot) switches. Cool
air flows in from the left side of the chassis, circulates through the chassis and the interface card, and
exhausts out the right side of the chassis.
