13
Figure 13 1U bracket rear mounting position
Figure 14 2U bracket front mounting position
NOTE:
• Installing the 2U mounting brackets in the rear mounting position is the same as installin
the brackets
in the front mounting position.
• To install the 2U mounting brackets in the mid-mounting position of a 2U switch chassis, first use a
screwdriver to loosen the three captive screws and separate the mounting brackets from the cable
management brackets (see Figure 15).
Figure 15 Separating a cable management bracket from a mounting bracket
(1) Captive screws (2) Cable management bracket (3) Mounting bracket
