52
Product
code
Module
description
Central
wavelength
(in nm)
Connector
Cable/fiber
specifications
Max transmission
distance
JG081C
HP X240 10G
SFP+ SFP+ 5m
DA Cable
N/A N/A SFP+ cable 5 m (16.4 ft)
JC784C
HP X240 10G
SFP+ SFP+ 7m
Direct Attach
Copper Cable
N/A N/A SFP+ cable 7 m (22.97 ft)
The following subsections describe several HP recommended IRF connection schemes, and all these
schemes use a ring topology.
IMPORTANT:
In these schemes, all physical IRF ports are located on the same side. If physical IRF ports are on differen
t
sides, you must measure the distance between them to select an appropriate cable.
Connecting the IRF member switches in one rack
Use short-haul and long-haul SFP+ cables to connect the IRF member switches (10 switches in this
example) in a rack as shown in Figure 66. T
he switches in the ring topology (see Figure 67) are in the
same order as connected in the rack.
