55
Appendix C Ports and LEDs
Ports
Console port
Every switch has one console port.
Table 16 Console port specifications
Item S
ecification
Connector type
RJ-45
Compliant standard
EIA/TIA-232
Transmission baud rate 9600 bps (default) to 115200 bps
Services
• Provides connection to an ASCII terminal.
• Provides connection to the serial port of a local PC running terminal
emulation program.
Management Ethernet port
The switches have a management Ethernet port. You can connect this port to a PC or management
station for loading and debugging system software or remote management.
Table 17 Management Ethernet port specifications
Item S
ecification
Connector type RJ-45
Connector quantity 1
Port transmission rate 10/100/1000 Mbps, half/full duplex
Transmission medium
and max transmission
distance
100 m (328.08 ft) over category-5 twisted pair cable
Functions and services Switch software and Boot ROM upgrade, network management
10/100/1000Base-T Ethernet port
Every switch has 10/100/1000Base-T Ethernet ports.
Table 18 10/100/1000Base-T Ethernet port specifications
Item S
ecification
Connector type
RJ-45
