58
Product
code
Description
Central
wavelength
(nm)
Fiber diameter
(μm)
Max. transmission
distance
JD101A
HP X110 100M SFP LC
BX 10-D Transceiver
TX: 1550
RX: 1310
9/125 15 km (9.32 miles)
IMPORTANT:
You must use the HP X110 100M SFP LC BX 10-U Transceiver (JD100A) and the HP X110 100M SFP LC BX 10-
D Transceiver (JD101A) in pairs.
For the SFP transceiver module specifications, see HP A-Series Switches Transceiver Modules User
Guide.
NOTE:
• To guarantee the functionality of the SFP ports, use only HP SFP transceiver modules.
• The SFP transceiver modules available for this switch series are subject to change over time. For the
most up-to-date list of SFP transceiver modules, consult your HP sales representative or technical
support engineer.
NOTE:
The SFP ports (numbered 49 and 50) and the last two 10/100/1000Base-T Ethernet ports (numbered
7 and 48) on an 48G model or 48G TAA model switch forms two combo interfaces. Ports 49 and 47
form one combo interface, and ports 50 and 48 form another. Only one port in a combo interface can
ork at a time.
SFP+ port
Every switch has SFP+ ports, and you can plug the SFP+ transceiver modules, SFP transceiver modules,
and SFP+ cables in Table 19, Table 21, or Table 22 i
nto the SFP+ ports as needed. You can use the
SFP+ ports as IRF physical ports to connect the switches in an IRF deployment.
Table 21 10 Gbps SFP+ transceiver modules available for the SFP+ ports
Product
code
Description
Central
wavelength
(nm)
Fiber
diameter
(μm)
Multi-mode
fiber modal
bandwidth
(MHz × km)
Maximum transmission
distance
JD092B
HP X130 10G
SFP+ LC SR
Transceiver
850
50/125
2000 300 m (984.25 ft)
500 82 m (269.03 ft)
400 66 m (216.54 ft)
62.5/125
200 33 m (108.27 ft)
160 26 m (85.3 ft.)
JD093B
HP X130 10G
SFP+ LC LRM
Transceiver
1310
50/125
1500 220 m (721.78 ft)
500 220 m (721.78 ft)
400 100 m (328.08 ft)
62.5/125 200 220 m (721.78 ft)
