6. Pull the locks on the bezel outward, then push evenly on both ends
of the bezel until it engages fully and the locks swing inward to about
45°. (See figure 1-7.)
7. Push the two locks evenly to close them, pressing downward slightly
to secure them in place.
8. Open the front door of the router by pulling its lock—the round post
at the upper right—to the right.
Figure 1-7. Reinstalling Interface Card
Figure 1-8. Opening Router Door
Installation
Install interface card(s).
1-11
