• You can exit without booting; then you will boot using the
procedure described at the end of this list on page 1-23. After
exiting, you will return to the Main menu.
Configuration Editor can be used after using Quick Configuration
if your network design calls for such features as spanning tree
bridging, static routes, or filtering, or if you have other requirements
for interoperating with other devices. The Configuration Editor
presents a hierarchy of menus and screens that include all
parameters available for customizing and integrating the router into
your network (including the subset of parameters you can access
through Quick Configuration).
At the Main menu (see figure 1-14), press [3] to select “Configuration
Editor.”
• For details on using the Configuration Editor, saving your
changes, and exiting, refer to the User’s Guide. After exiting, you
will return to the Main menu.
• Then you will boot the router using the procedure described at
the end of this list (page 1-23).
Configuration Editor
Selection Pointer
Date and Time
Figure 1-14. Main Menu Screen
Installation
Configure and boot the router.
1-21
