HP 650C User Manual

10-8 Parts and Diagrams
Parts List, C2859A Electronics Enclosure
Ref.
Des.
HP Part
Number
C
D
Qty Description
1 0515-1249 4 19 SCREW, MACH
2 C2858-60105 3 1 PCA, INTERCONNECT
3 156474 2 1 IC EEROM (U42)
4 C2065A
C2066A
4
5
SIMM 4MB (OPTION: SEE CHAPTER 1)
SIMM 8MB (OPTION: SEE CHAPTER 1)
5 C2847-40007 9 1 BARRIER, SIMM
6 0535-0043 6 2 NUT, HEX M4X 0.7
7 C2858-18012
C2858-18013
C2858-18014
C2858-18015
2
3
4
5
1
1
1
1
IC, PROGRAMMED, EPROM 0 (U31)
IC, PROGRAMMED, EPROM 1 (U30)
IC, PROGRAMMED, EPROM 2 (U33)
IC, PROGRAMMED, EPROM 3 (U32)
8 MODULE, ROM (OPTION: SEE CHAPTER 1)
9 C2858-69104 0 1 PCA, MAIN (REBUILT) ; C2858-60104 CD=2 (NEW)
10 0515-0380 2 15 SCREW, MACH M4X10
11 C1633-00033 7 1 SUPPORT, MIO
12 C1633-40059 1 2 GUIDE, MIO SUPPORT
13 9170-1535 8 2 FERRITE, SPLIT-RECT
14 C2858-60024 5 1 CABLE ASSEMBLY, TRAILING
15 9170-1533 6 2 CLAMP, FERRITE
16 0400-0369 4 1 GROMMET, CHANNEL
17 C1633-00031 5 1 COVER, MIO
18 0570-1316 2 2 SCREWLOCK, FEMALE (RS-232)
19 0515-1084 5 2 SCREW, MACH M3X12
20 C2848-60001 6 1 ELECTRONICS ENCLOSURE ASSEMBLY
21 1400-1642 9 2 CLIP, CABLE-FLAT
22 0515-2246 3 10 SCREW, TORX/SLOT M3
23 0515-0390 4 1 SCREW, MACH M4X6
24 C1633-60020 8 1 AC POWER RECEPTACLE ASSEMBLY
25 1400-1021 8 1 CLIP, CABLE 1 IN LG
26 C1633-00080 4 1 INSULATOR, BOTTOM
27 3160-0814 7 1 FAN, TUBEAXIAL
28 0515-1349 5 2 SCREW, MACH M3
29 0950-2417 2 1 PCA, POWER SUPPLY
30 C2847-00019 9 1 INSULATOR, POWER SUPPLY
31 C1633-00105 4 1 LABEL, INSULATOR
32 C1633-60014 0 1 CABLE ASSEMBLY, MAIN BD PWR
33 C2848-00002 1 1 COVER, ELECTRONICS ENCLOSURE
34 C2847-00027 9 1 COVER, SIMM
35 C2858-60011 0 1 CABLE ASSEMBLY (WIRE HARNESS)
