10-18 Parts and Diagrams
Parts List, Carriage Axis Drive (Left End)
Ref.
Des.
HP Part
Number
C
D
Qty Description
1 C2847-00029
1500-0856
1
7
1
1
BELT, MAIN DRIVE MODEL C2858A
MODEL C2859A
2 07570-60105 1 1 MAIN IDLER ASSEMBLY
3 07570-40105 9 1 TENSIONER, MAIN
4 1460-2139 7 1 SPRING, COMP 1.07 OD
5 C1633-40065 9 1 HOUSING, MAIN TENSIONER
6 0515-0380 2 4 SCREW, MACH M4X10
7 C1633-00068 8 1 DOOR, TENSIONER HOUSING
8 C2858-00028
C2859-00005
3
7
1
1
TRAILING CABLE TRAY, FRONT MODEL C2858A
MODEL C2859A
9 0515-2248 9 3 SCREW, THRD RLLG
10 C1633–00057 5 1 BRACKET, Y-AXIS TENSIONER
11 1400-1021 8 2 CLAMP, CABLE 1 IN LG
12 C2847-00042
C2848-00011
8
2
1
1
ENCODER STRIP MODEL C2858A
MODEL C2859A
13 3050-0026 0 1 WASHER, 3.2MM
14 0535-0031 2 1 NUT, HEX, M3X0.5
15 0624-0647 5 2 SCREW, 6-20 PLASTITE
16 C2858-60007 4 1 SENSOR, PRIMER
17 C2858-60003 0 1 PRIMER ASSEMBLY
18 C2858-00077 2 1 GROUND STRAP
19 C2858-40038 9 1 INK DROP RESERVOIR (LEFT SPITTOON)
20 C2858-00076 1 1 ABSORBENT MATERIAL
21 C2858-00012 5 4 TUBES, RUBBER
