HP 830 - Specifications for Transceiver Modules Applicable to the HP 830 Uplink Module

42
Item Specification
Transmission distance 70 km (43.50 miles)
Transmission rate 1250 Mbps
Connector type Duplex LC
Fiber mode SMF
Transmit power –4 to +5 dBm
Receive sensitivity ≤ –22 dBm
Saturation ≤ –3 dBm
Specifications for transceiver modules applicable to
the HP 830 uplink module
Table 18 XFP-SX-MM850 specifications
Item Specification
Central wavelength 1310 nm
Transmission distance 300 m (984.25 ft)
Transmission rate 10.31 Gbps
Connector type Duplex LC
Fiber mode MMF
Transmit power –7.3 to –1.08 dBm
Receive sensitivity ≤ –11.1 dBm
Saturation ≤ –1 dBm
Table 19 XFP-LX-SM1310 specifications
Item Specification
Central wavelength 1310 nm
Transmission distance 10 km (6.21 miles)
Transmission rate 10.31 Gbps
Connector type Duplex LC
Fiber mode SMF
Transmit power –8.2 to +0.5 dBm
Receive sensitivity ≤ –12.6 dBm
Saturation ≤ 0.5 dBm
